WooSync for Perfex CRM - Ultimate WooCommerce Synchronization Plugin
384.70 msEnterprise WooCommerce ↔ Perfex CRM Synchronization Hub module establishing real-time bi-directional sync.
WooSync (woosync) is an enterprise-grade WooCommerce ↔ Perfex CRM Synchronization Hub module. It establishes real-time, bi-directional synchronization between WooCommerce stores and Perfex CRM using a Webhook-First + Cron-Fallback architecture.
It synchronizes Products (simple, variable, grouped, external), Product Categories (hierarchical tree), Tags, Attributes & Terms, Orders, Customers, Refunds, Coupons, and Taxes. It automatically maps WooCommerce orders to Perfex CRM Clients & Invoices, provides automated Reverse Sync (updating WooCommerce order status when a Perfex Invoice is paid), supports High-Performance Order Storage (HPOS), multi-currency conversion, and multi-store management.
Official Documentation & User Guides
- WooSync Installation & Usage Guide - Step-by-step installation, WooCommerce API key generation, and webhook setup.
- Complete WooSync Setup Guide - Comprehensive configuration guide covering multi-store linking, field mapping, reverse sync, and initial data synchronization.
Core Feature Subsystems
1. Webhook-First + Cron-Fallback Architecture
- Inbound Webhook Receiver: Instant real-time event processing triggered by WooCommerce webhooks with HMAC-SHA256 signature verification (
hash_equals()). - Cron Delta Sync Fallback: Scheduled background runner polling missed updates to ensure zero data loss during network hiccups.
2. Multi-Store WooCommerce Management
- Unlimited Store Connection: Manage multiple WooCommerce stores from a single Perfex CRM control dashboard.
- Encrypted Store Credentials: Store API Consumer Keys and Secrets using OpenSSL AES-256-CBC encryption.
3. WooCommerce Order-to-Invoice & HPOS Support
- Automatic Client & Invoice Mapping: Converts WooCommerce orders into Perfex CRM Client profiles and Invoices automatically.
- High-Performance Order Storage (HPOS): Compatible with WooCommerce HPOS custom order tables.
- Multi-Currency Conversion & Line Items: Map store currencies to Perfex CRM currencies, including shipping fee line items and tax calculations.
4. Reverse Sync Engine (Perfex Invoice Paid → WooCommerce Order Status)
- Automatic Status Update: Automatically transitions WooCommerce order status (e.g. Processing → Completed) when the corresponding Perfex Invoice is marked as paid.
5. Product, Category, Tag & Attribute Hierarchical Sync
- All Product Types Supported: Bi-directional sync for Simple, Variable, Grouped, and External products.
- Hierarchical Category Tree & Terms: Sync nested WooCommerce product categories, tags, and custom attributes seamlessly.
6. Customer Sync & Automatic Contact Matching
- Client Profile Linking: Sync WooCommerce customers into Perfex CRM Clients & Contacts with automatic email deduplication.
- Shipping & Billing Address Mapping: Automatically populate customer billing and shipping address fields.
7. Coupons, Refunds & Credit Note Engine
- Refund & Credit Note Generator: Sync WooCommerce order refunds directly into Perfex CRM Credit Notes.
- Coupon Discount Mapping: Map store promotional coupons and discount rules into invoice line item adjustments.
8. Synchronization Audit Logs & Queue Monitoring
- Detailed Activity Logs: Comprehensive audit trail capturing API payloads, status codes, timestamps, and error tracebacks.
System Architecture & Synchronization Data Workflow
graph TD
subgraph WooCommerce Store ["WooCommerce Store (E-Commerce Platform)"]
WC_Order["Order Placed / Updated"]
WC_Customer["Customer Registered"]
WC_Product["Product / Category Created"]
WC_Refund["Order Refund Triggered"]
WC_HPOS["HPOS (High-Performance Order Storage)"]
end
subgraph SyncEngine ["WooSync Synchronization Hub Engine"]
WH_Receiver["Inbound Webhook Receiver<br/>(HMAC-SHA256 Signature Verification)"]
Cron_Runner["Cron Delta Sync Fallback<br/>(Scheduled Polling Runner)"]
Queue_Log["Queue & Audit Logger<br/>(Payload Tracking & Retries)"]
AES_Enc["AES-256-CBC Encrypted Store API Keys"]
end
subgraph PerfexCRM ["Perfex CRM (Enterprise Platform)"]
CRM_Client["Clients & Contacts Database"]
CRM_Invoice["Invoices & Line Items"]
CRM_Item["Products, Categories & Attributes"]
CRM_Credit["Credit Notes & Refund Records"]
CRM_Payment["Invoice Paid Status Event"]
end
WC_Order -->|Real-time Inbound Webhook| WH_Receiver
WC_Customer -->|Real-time Inbound Webhook| WH_Receiver
WC_Product -->|Real-time Inbound Webhook| WH_Receiver
WC_Refund -->|Real-time Inbound Webhook| WH_Receiver
WC_HPOS -.->|Scheduled Delta Poll| Cron_Runner
WH_Receiver --> Queue_Log
Cron_Runner --> Queue_Log
Queue_Log -->|Auto-Create / Link Contact| CRM_Client
Queue_Log -->|Auto-Generate Invoice| CRM_Invoice
Queue_Log -->|Hierarchical Catalog Sync| CRM_Item
Queue_Log -->|Generate Credit Note| CRM_Credit
CRM_Payment -->|Reverse Sync Engine| WC_Order
Reverse Sync Engine Workflow
graph TD
A["Perfex CRM Invoice Marked Paid"] --> B["Woosync_reverse_sync Engine Triggered"]
B --> C{"Check Status Mapping Configuration"}
C --> D["Resolve WooCommerce Store ID & Order ID"]
D --> E["Decrypt API Secret Key via OpenSSL AES-256-CBC"]
E --> F["Initialize WooCommerce REST API Client (wc/v3)"]
F --> G["Send PUT Request to /wp-json/wc/v3/orders/{id}"]
G --> H{"HTTP Response 200 OK?"}
H -->|"Success"| I["Update Store Order Status (Processing -> Completed)"]
H -->|"Failure"| J["Log Status Exception & Enqueue into Retry Queue"]
Order-to-Invoice Conversion & HPOS Field Mapping
graph TD
A["New Order Placed on WooCommerce Store (HPOS Order)"] --> B["Inbound Webhook order.created Listener"]
B --> C["Verify HMAC-SHA256 Signature Secret"]
C --> D{"Customer Email Exists in Perfex CRM?"}
D -->|"No"| E["Auto-Create New Client Profile & Contact"]
D -->|"Yes"| F["Link Order to Existing Client Profile"]
E --> G["Map Billing & Shipping Location Addresses"]
F --> G
G --> H["Convert Store Currency & Sales Tax"]
H --> I["Auto-Generate Perfex CRM Invoice (Unpaid)"]
I --> J["Record Item Lines, Shipping Fee & Coupon Adjustments"]
Multi-Store Connection & Security Workflow
graph TD
A["Admin Adds New WooCommerce Store"] --> B["Input Store URL, Consumer Key, Consumer Secret & Webhook Secret"]
B --> C["Encrypt Credentials using OpenSSL AES-256-CBC"]
C --> D["Persist Record in woosync_stores Table"]
D --> E["Auto-Register Inbound Webhook Endpoints"]
E --> F["Test Connection via WooCommerce REST Client v3"]
F --> G{"Connection Status 200 OK?"}
G -->|"Success"| H["Activate Store Status & Start Real-Time Sync"]
G -->|"Failure"| I["Log Alert Error & Display Credential Warnings"]
